Granulation equipment series

GHL Series High Speed ​​Mixing Granulator

Summay:GHL series high-speed mixing granulator is fully mixed with powder material and adhesive in the cylindrical container from the bottom mixing slurry into a wet soft material, and then cut into uniform wet particles by the side-mounted high-speed crusher. .

Detailed description

Working Principle
 Powder material and adhesive are fully mixed into a moist soft material in the cylindrical container from the bottom mixing slurry, and then cut into uniform wet particles by high-speed pulverizing paddles placed on the side.


   Performance characteristics
 ◎ This machine adopts horizontal cylinder structure, reasonable structure.
 ◎ Inflatable sealed drive shaft, switchable to water when cleaning.
 ◎ fluidized granulation, granulation approximate spherical, good fluidity.
 ◎ 25% less adhesive than traditional process, shorter drying time.
 ◎ Only dry mix 2 minutes for each batch, granulation 1-4 minutes, 4-5 times more efficient than traditional process.
 ◎Complete in the same closed container, dry mix-wet mix-granulation, process shortening.
 ◎ The entire operation has strict safety protection measures.
 ◎ can be made according to user requirements jacket type.


   Technical specifications

modelABC×DEF
503209501250×8009701650
1504201,0001350×80010501750
20050011001650×94014502050
25050011601650×94014002260
30055012001700×100014002310
40067013001860×110015502410
60075015002000×123017502610



namemodel
50150200250300400600
Volume L50150200250300400600
Yield kg/batch155080100130200280
Mixing speed rpm200/400180/270180/270180/270140/220106/15580/120
Hybrid power kw4/5.56.5/89/119/1113/1618.5/2222/30
Cutting speed rpm1500/30001500/30001500/30001500/30001500/30001500/30001500/3000
Cutting power kw1.3/1.82.4/34.5/5.54.5/5.54.5/5.56.5/89/11
Compressed air consumption m3/min0.60.90.90.91.11.51.8
Weight kg5008001,0001300180022002600
