Other equipment series

Alcohol recovery tower

Summay:The alcohol recovery tower uses highly efficient ceramic corrugated packing. The distillation column body is made of stainless steel, thus preventing the iron filings from clogging the filler and prolonging the service life of the device. All parts of the device that come into contact with alcohol, such as condensers, surge tanks, and cooling coils, are made of stainless steel to ensure that the finished alcohol is not contaminated.

Detailed description

Equipment structural characteristics and technical performance
     The device uses highly efficient ceramic corrugated packing. The distillation column body is made of stainless steel, thus preventing the iron filings from clogging the filler and prolonging the service life of the device. All parts of the device that come into contact with alcohol, such as condensers, surge tanks, and cooling coils, are made of stainless steel to ensure that the finished alcohol is not contaminated. The W-type distillation pot adopts a detachable U-shaped heating pipe. During the inspection, the U-shaped heating pipe can be removed from the kettle to facilitate the cleaning of the outer wall of the heating pipe and the inner wall of the distillation pot.
   The ZW type eliminates the need for an indirect heating still. Condenser tube heat exchanger, but also according to user requirements to supply spiral plate heat exchanger, cooler coil cooler, using coil cooler and matching supply tank and specific gravity measuring device.
 Product Usage
   The device is applicable to the dilute alcohol recovery in pharmaceutical, food, light industry, chemical industry and other industries. Also suitable for the distillation of other solvents such as methanol. According to the user's requirements, this device can dilute about 30° of dilute alcohol to 90-95° alcohol. If the finished product requires a high degree of alcohol, the reflux ratio can be increased, but the production is reduced accordingly.   There are five types
 of  W-type device composition , each type includes the corresponding configuration of the distillation tower, distillation kettle, condenser, cooler, regulator tank, specific gravity measuring device. Among them, the W-200 and W-300 distillation towers are installed directly on the distillation still. The W-400, W-500, and W-600 distillation columns were installed separately from the distillation stills.
   ZW-type ZW-200, ZW-300 two specifications, each specification includes the corresponding supporting preheater, distillation tower, condenser, cooler, regulator tank, specific gravity measuring device.
   Other auxiliary equipment and instruments such as: metering tanks, storage tanks, transfer pumps, rotameters, temperature indicating instruments and other user-owned, our factory can also be processed according to user requirements or on behalf of the order supply.
 Technical parameters
 ◎ feed concentration: 30% to 80%
 ◎ discharge concentration: 90% to 95%
 ◎ reflux ratio: R = 13 (according to the inlet and outlet material concentration )
 ◎ residue discharge alcohol concentration: W type ≤ 3% , ZW ≤ 1%
 ◎Production capacity (kg/h): See the table on the right

modelTower diameter
       (mm)
30% to 40% feed capacity60%-80% feed capacity
90%95%90%95%
W-200Φ20035264536
W-300Φ300806110080
W-400Φ400150120180140
W-500Φ500230185275220
W-600Φ600335270400320
ZW-200Φ200956011080
ZW-300Φ300200120240165
