Other equipment series

TJG fixed lifting feeder

Summay:TJG series fixed lift feeder consists of two parts, namely hoist and base. The hoist consists of a frame, a hydraulic lifting system and a material turnover mechanism. During work, the hoisting machine's material door is first engaged with the material barrel, and the lifting operation lever is started. The material door is raised together with the material barrel, and the turning operation lever is started. The material barrel can be rotated 180 degrees and the bottom barrel is upwardly moved and moved. To the desired location, the use of the material discharge valve on the material door makes it easy to add the material to the required process equipment.

Detailed description

Overview
  TJG series fixed lift feeder consists of two parts, namely hoist and base. The hoist consists of a frame, a hydraulic lifting system and a material turnover mechanism. During work, the hoisting machine's material door is first engaged with the material barrel, and the lifting operation lever is started. The material door is raised together with the material barrel, and the turning operation lever is started. The material barrel can be rotated 180 degrees and the bottom barrel is upwardly moved and moved. To the desired location, the use of the material discharge valve on the material door makes it easy to add the material to the required process equipment.

Technical specifications

Model Specifications\ParametersHADH1
TJG-502050650Φ4852900
TJG-1002050750Φ5902900

Technical specifications

nameLoading capacity (kg)Specifications (barrel height x height)Wall thickness (mm)
Material bucket50Φ485×4600.8
100Φ590×5500.8
Drum special car50-100Φ500×600
